Installation; Type 1 - Regular Key - Directed VW02 Firmware Specific Manual

Installation

Type 1 - Regular Key

(+) Starter: Red/Black
or Black, pin 1
1 2 3
G plug
7 8
at VESCM
FT CAN Low: Orange/ Brown, pin 7
1 2 3 4 5 6 7
8
16
9 10 11 12 13 14 15
(-) Clutch: Violet/Black, pin 7
[4]
The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory hood pin.
[1]
The siren is only compatible with Directed Digital Hybrid Systems.
[2]
For Key Wrap instructions refer to pages 7-10.
[3]
For manual transmission vehicle only.
[4]
With the exception of the OBDII diagnostic connector, all connectors are displayed from the wire side (unless specified otherwise).
11
(+) Ignition: Black or
Black/Green, pin 11
4 5 6
11 12
9 10
FT CAN High: Orange/Green: 7
FT CAN High: Orange/Green, pin 8
FT CAN Low: Orange/Brown: 8
(+) Starter Output: Green/Red: 14
Hood Pin
E plug
at VESCM
[1]
(-) Clutch Output: Dk.Blue: 7
(+) Siren Output: Brown: 17
[2]
Siren
E
Manual/Auto. Transmission Type
Manual/Auto. Transmission Type
(-) Hood Input: Gray: 3
VESCM - Driver side,
under dashboard
F G
H
Prog.
Prog.
Button
Button
Remote Start Safety
Override Switch
The Remote Start
Safety Override
Switch MUST be in
the ON position.
10: Red: (+) 12V
9: Black: (-) Ground
5: Orange/Red: Key Wrap
4: Yellow/Red: Key Wrap
3: Brown/Red: Key Wrap
2: White/Brown: (+) Ignition Output
1: White: (+) 12V
(+) 12V
(-) Ground
[3]
[3]
[3]
Directed Digital System VW02
© 2016 Directed. All rights reserved.
