Alternate clutch connection for Audi R8 (Type 4)

28
94
15
2x 1Amp Diodes
(-) Clutch: (-) Clutch:
Green/Gray,
Gray/Blue,
pin 41 pin 39
7
73
(-) Clutch Output: Dk. Blue: 7
1
15
60
5
Engine Control Module (ECM)
located at the front right of the engine
compartment
Manual/Auto. Transmission Type
Manual/Auto. Transmission Type
Prog.
Prog.
Button
Button
1
46
