Analog harness (H3), 18-pin white connector

Conn./Pin
Color
H3/1
Lt. Blue/Red
H3/2
Black/White
H3/3
Gray
H3/4
N/A
H3/5
Gray/Black
H3/6
Violet/White
H3/7
Dark Blue
H3/8
Brown/Black
H3/9
Red/White
H3/10
White/Green
H3/11
Yellow/Green
H3/12
Blue/Red
H3/13
Light Blue
H3/14
Pink/Yellow
H3/15
Dark Green
H3/16
Brown/White
H3/17
Brown
H3/18
Blue/White

MC501 harness (H4), 8 thick-gauge wires (optional)

Conn./Pin
Color
H4/1
Pink/White
H4/2
Red/White
H4/3
Pink
H4/4
Red
H4/5
Orange
H4/6
Red
H4/7
Green
H4/8
Violet
1.
If these outputs are not used by the firmware, they can be configured by the installer when the module is flashed. Note that they are
low current and a relay may be necessary.
2.
These connections are only required if the corresponding statuses are not supported by the firmware. See "Vehicle application guide"
on page 4 for a list of compatible features.
6
Description
No Connection
(-) Parking Brake Input (Manual Transmission)
(-) Hood Input
2
No Connection
(+) Glow Plug Input
2
(AC) Tach Input
2
(-) Clutch Output (Manual Transmission)
Horn
1
(-) Trunk Release Output
1
(-) Door Input
2
(+) Door Input
2
No Connection
(-) Trunk Trigger Input
2
(-) Activation (Start Trigger) Input
Lock
1
(+) Brake Input
2
(+) Siren Output
1
(-) GWR (Ground While Running)
Description
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
2
1
Directed Digital System VW02
© 2016 Directed. All rights reserved.
