Type 10- Push-To-Start - Directed VW02 Firmware Specific Manual

Type 10 - Push-To-Start
B Plug
A Plug
(-) PTS: Violet/Black, pin 4
(Black) (White)
VESCM - Driver side,
(-) PTS: Violet/Yellow,
under dashboard
(-) Hazards:
Brown/Red, pin 28
(connect this wire
only if turn signals
16 37 73
don't work)
Arm/Disarm: Blue/Red, pin 24
(+) Brake: Black/Red,
[5]
pin 43
(-) Trunk Release:
Violet, pin 23
17
1 63
A Plug (Black)
at VESCM
The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory hood pin.
[1]
The siren is only compatible with Directed Digital Hybrid System.
[2]
For Key Wrap instructions refer to pages 7-10.
[3]
For manual transmission vehicles only.
[4]
For automatic transmission vehicles only.
[5]
With the exception of the OBDII diagnostic connector, all connectors are displayed from the wire side (unless specified otherwise).
21
(-) Clutch: Violet/White
[4]
or Violet/Black, pin 55
2 x 1Amp
1 8
Diodes
9 16
14
FT CAN High:
pin 13
Orange/Green,
pin 16
FT CAN Low:
Orange/Brown,
pin 15
(+) Brake Activation Output: Green/Red: 14
[5]
Siren
16 37 73
1 17 63
B Plug (White)
Manual/Auto. Transmission Type
Manual/Auto. Transmission Type
at VESCM
Door Locks: Violet/Brown: 1
FT CAN High: Orange/Green: 7
FT CAN Low: Orange/Brown: 8
Door Locks: Violet/Green: 9
(-) Hazards SW Output: Green/Black: 10
(-) PTS Output: Lt.Blue/Black: 13
Hood Pin
(-) Hood Input: Gray: 3
[1]
Clutch Output: Dk.Blue: 7
[4] (-)
(-) Trunk Release Output: Red/White: 9
(+) Siren Output: Brown: 17
[2]
Prog.
Prog.
Button
Button
Remote Start Safety
Override Switch
The Remote Start
Safety Override
Switch MUST be in
the ON position.
10: Red: (+) 12V (+) 12V
9: Black: (-) Ground (-) Ground
5: Orange/Red: Key Wrap
[3]
4: Yellow/Red: Key Wrap
[3]
3: Brown/Red: Key Wrap
[3]
Directed Digital System VW02
