Type 5 - Key Port - Directed VW02 Firmware Specific Manual

Type 5 - Key Port

VESCM - Driver side, under dashboard
E F G
H
Ignition Switch Plug
(located at Key Port)
(+) 12V Interrupt: Green/Red, pin 3
CUT
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
Keysense: Green,
pin 16
86 87 85
(+) 12V
87a
30
The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory hood pin.
[1]
The siren is only compatible with Directed Digital Hybrid Systems..
[2]
For Key Wrap instruction refer to pages 7-10.
[3]
For manual transmission vehicle only.
[4]
With the exception of the OBDII diagnostic connector, all connectors are displayed from the wire side (unless specified otherwise).
16
42 25 1 (-) Hazards: Brown/Red, pin 9
(connect this wire only if turn
28
(+) Brake:
29 12
Black/Red,
pin 17
52 41 24 11
C plug (Brown)
at VESCM
Note: Connect only on vehicle
where brake needs to be
depressed to start.
Diode
1A
Fuse 10A
(+)12V
87
86 85
87a
(-) Hazards SW Output: Green/Black: 10
30
1 2 3 4 5 6 7 8
16
9 10 11 12 13 14 15
Hood Pin
E plug
(-) Clutch:
[4]
at VESCM
Violet/Black, pin 7
Siren
signals don't work on CAN)
(+) Ignition:
Red/Violet,
pin 11
(+) Starter: Red/Gray
or Red/Violet, pin 1
1 2 3 4 5 6
G plug
at VESCM
7 8 9 10 11 12
FT CAN Low:
Orange/ Brown,
pin 7
FT CAN High:
Orange/Green, pin 8
Manual/Auto. Transmission Type
FT CAN High: Orange/Green: 7
FT CAN Low: Orange/Brown: 8
(+) Starter Output: Green/Red: 14
(-) Hood Input: Gray: 3
[1]
(-) Clutch Output: Dk.Blue: 7
[4]
(+) Siren Output: Brown: 17
[2]
(-) Key In Output: Blue/White: 18
Manual/Auto. Transmission Type
Prog.
Prog.
Button
Button
10: Red: (+) 12V
9: Black: (-) Ground
5: Orange/Red: Key Wrap
4: Yellow/Red: Key Wrap
3: Brown/Red: Key Wrap
2: White/Brown: (+) Ignition Output
1: White: (+) 12V
Remote Start Safety
Override Switch
The Remote Start
Safety Override
Switch MUST be in
the ON position.
(+) 12V
(-) Ground
[3]
[3]
[3]
Directed Digital System VW02
