Installation Guide

This guide supports the installation of a DBALL2 in Remote Start Ready (RSR) mode. This solution

offers

three (3)

configuration options to control your system:

Kit or SmartStart (both sold separately).

Remote Start Ready (RSR) is a function that enables the interface module to remote start the vehicle

completely on its own. Consequently, there is no need for an aftermarket or an OEM remote starter in order to

start the vehicle from a distance.

Important!

This product is NOT compatible with vehicles equipped with a manual transmission.

Index

Vehicle Application Guide...................................................................................................................................................

Installation (Wiring Diagrams & Vehicle Wiring Reference Charts)

Type 1.................................................................................................................................................................................

Type 2.................................................................................................................................................................................

Programming

Notes..................................................................................................................................................................................

Module Programming.........................................................................................................................................................

Module Reset.....................................................................................................................................................................

Hard Reset.........................................................................................................................................................................

Feature & Option List..........................................................................................................................................................

Feature Programming.........................................................................................................................................................

LED Diagnostics & Troubleshooting...................................................................................................................................

Parking Lightg Error Codes................................................................................................................................................

Limited One-Year Consumer Warranty...............................................................................................................................

Quick Reference Guide......................................................................................................................................................

SmartStart Compatible

SmartStart is equipped with D2D, which means it can be connected to an interface module and used in Remote

Start Ready (RSR) mode without the use of a remote starter. See the Module Programming section for more

information.

® Hyundai is a registered trademark and property of its respective company.

3x OEM Lock Remote Start Activation,

Rev.: 20161207

Table of Contents

Summary of Contents for Directed DBALL2

Page 1: Installation Guide
Update Alert: Firmware updates are posted on the web on a regular basis. We recommend that you check for firmware and/or install guide updates prior to installing this product. Installation Guide This guide supports the installation of a DBALL2 in Remote Start Ready (RSR) mode. This solution offers three (3)
Page 2: Vehicle Application Guide
PK: Transponder & Immobilizer Override •: D2D & Wire-to-Wire (W2W) AV: Horn & Lights Controls DL: OE Door Lock & Alarm Controls RS: Remote Start & Engine Controls SS: Integrated Security & Monitoring ST: Function/Feature Status © 2016 Directed. All rights reserved.
Page 3: M01-L
Tach wire is an optional connection required on some remote starters, which do not support a tach signal in D2D. With the exception of the OBDII Diagnostic connector, all adapters are displayed from the wire side (unless specified otherwise). © 2016 Directed. All rights reserved.
Page 4: Type
White/Orange Data EM11, driver kick panel. Black FT CAN High Blue Data MF11, driver kick panel. White FT CAN Low Data MF11, driver kick panel. White Locating components in the vehicle Driver Kick Panel © 2016 Directed. All rights reserved.
Page 5: M01-L
Tach wire is an optional connection required on some remote starters, which do not support a tach signal in D2D. With the exception of the OBDII Diagnostic connector, all adapters are displayed from the wire side (unless specified otherwise). © 2016 Directed. All rights reserved.
Page 6: M01-L
White/Orange Data EM11, driver kick panel. White FT CAN High Blue Data MF11, driver kick panel. White FT CAN Low Data MF11, driver kick panel. White Locating components in the vehicle Driver Kick Panel © 2016 Directed. All rights reserved.
Page 7: Module Programming
Firmware: HYUNDAI4 Remote Start Ready (RSR) Installation Rev.: 20161207 Page 7 SmartStart/XL202 Installation Notes The DBALL2 Remote Start Ready (RSR) solution offers three (3) configuration options to control your system: 3x OEM Lock Remote Start Activation, RF Kit or SmartStart (all sold separately) .
Page 8 Note: Before connecting either the XL202 or SmartStart module to DBALL2, it is important to ensure that the proper feature and function programming is selected using XpressVIP (version 4.5 or higher). Visit www.directechs.com to download the latest version of the application.
Page 9: Hard Reset
Wait 3 seconds until the LED turns ON solid orange, and wait 10 more seconds & until the LED starts to flash orange and red. Solid Flashes & Release the programming button. The LED turns ON solid red. Release Solid © 2016 Directed. All rights reserved.
Page 10: Feature & Option List
Priority Unlocks all doors on first press. The OEM alarm will not be controlled by DBALL2 upon remote start. No disarm or arm command will be 1. Disabled executed at the beginning or end of the sequence; it must be controlled by the Remote Starter.
Page 11: Feature Programming
No activity for 30 seconds; after 30 seconds, the LED will turn ON orange for 2 seconds to confirm the end of the programming sequence. Press and HOLD the programming button for 3 seconds. After 3 seconds, the LED will turn ON orange for 2 seconds to confirm the end of the programming sequence. © 2016 Directed. All rights reserved.
Page 12: Led Diagnostics & Troubleshooting
The Violet/Green or Violet/Brown wire did not detect the expected voltage value. Refer to "Installation (wiring Flashes red MUX not detected. diagrams & vehicle wiring reference charts)" to check the connections. © 2016 Directed. All rights reserved.
Page 13 The smart key was not detected, which prevents the Flashes red Smart key was not detected. system from shutting down the vehicle. The vehicle was detected as moving, which prevents the Flashes red Speed was detected. system from shutting it down. © 2016 Directed. All rights reserved.
Page 14 Brake shutdown. Hood shutdown/Remote start safety override switch is ON*. Remote start safety override switch is ON*. * If the vehicle hood status is supported through data, safety override switch input will report 7 flashes. © 2016 Directed. All rights reserved.
Page 15 Part was purchased from an authorized DIRECTED dealer; and the Part is returned to DIRECTED, postage prepaid, along with a clear, legible copy of the receipt or bill of sale bearing the following information: consumer’s name, address, telephone number, the authorized licensed dealer’s name and complete...
Page 16: Quick Reference Guide
Quick Reference Guide DBALL2-HYUNDAI4 Remote Start Ready (RSR) Installation Vehicle Takeover Pit Stop Mode The Pit Stop Mode feature is practical when you need to stop and run an errand, but wish to keep the engine running. Press Press the remote start button on the transmitter to remote start start the vehicle.*...
Page 17 3.0 enables a "Cloud-Connected Car" like never before, providing an entirely new the trunk release (optional). level of 2-way interaction with your vehicle. Connectivity is managed through the Directed Cloud Services (DCS) network linking car, app, end user, and the Internet. Press once, then...
Page 18 Quick Reference Guide DBALL2-HYUNDAI4 Remote Start Ready (RSR) Installation Engine Idle Protection System (EIPS) Vehicles equipped with RFID-type Push-to-Start ignition systems work by detecting Activating/deactivating EIPS: a proximity key in the vehicle. They will run indefinitely if the key is removed, which To activate EIPS, remove all keys from the vehicle and close all doors while the §...
