LED diagnostics and troubleshooting

This section provides LED diagnostics and troubleshooting information to guide you through the various stages of
your installation.
Module programming – Firmware specific
LED Description
Module has no
power.
Off
Module is powered.
Waiting to begin
the programming
Solid red
sequence.
CAN bus detected,
car detection in
progress.
Flashes green
Module programming – Error codes
LED Description
FT CAN not
detected.
Flashes red x 1
HS CAN not
detected.
Flashes red x 2
Ignition not
detected.
Flashes red x 3
VIN not detected.
Flashes red x 4
Internal error.
Flashes red x 5
Shutdown codes
LED Description
Run safe shutdown.
Flashes red x 1
Brake shutdown.
Flashes red x 2
Active ground when running (status)
LED Description
GWR (Status)
command received.
Flashes green
28
Troubleshooting
Make sure the D2D harness is connected or that
the 12 volt is present between the red and black
wires. If the 12 Volt is present, the module may be
defective.
Verify your power lines
Check the firmware name and version.
Troubleshooting
Check CAN connection.
Check the firmware name and version.
Report the error to tech support.
Troubleshooting
Used to check the installation and for troubleshooting
purposes.
Troubleshooting
Used to ensure the module has received the remote
start message and has enabled the remote start
runtime.
Comment
Normal operation.
Normal operation.
Comment
Comment
Used to check for internal safety operation.
Does not represent an error.
Comment
Commands can come from RF, D2D or
W2W.
