1. Place the module next to the controller against the panel where you are
2. Mark drilling holes through the mounting screw holes and mounting feet,
3. Drill the holes at the markings.
4.
2.4.2 Wiring Diagram
Hazard of damage to the terminal connector.
WARNING
The Spectrum Controls RTB hold down and terminal screws must be
tightened by hand using the guidelines. They must not be tightened using a
power tool. Use a screwdriver of 0.8 × 2 mm and tighten to no more than
0.25 N-m (2.2 lb-in) torque.
Failure to follow these guidelines may result in damage to your connector.
The following images explain the general layout of the module terminal blocks
and the associated wiring diagrams for the various input signals and the 2085sc-
IF16C or 2085sc-IF16V module:
RTB1#
Name
1
IN0+
2
IN0-
3
IN1+
4
IN1-
5
IN2+
6
IN2-
7
IN3+
8
IN3-
9
IN4+
10
IN4-
11
IN5+
12
IN5-
13
IN6+
14
IN6-
15
IN7+
16
IN7-
17
NC
18
NC
mounting the module.
and then remove the module.
Replace the module and mount it. Leave the protective debris strip in
place until you are finished wiring the module, and any other devices.
RTB2#
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
Chapter 2: Installation and Wiring
Name
IN8+
IN8-
IN9+
IN9-
IN10+
IN10-
IN11+
IN11-
IN12+
IN12-
IN13+
IN13-
IN14+
IN14-
IN15+
IN15-
NC
NC
User's Manual Pub. 0300306-02 Rev. B
2-7
