Input Description
Storage/Non-Operating Humidity
Vibration/Operating
Operating Shock
Storage/Non-Operating Shock
Pollution Level
ESD
Radiated Immunity
Inputs per module
Input ranges
Input filters
Current accuracy
(4 and 17 Hz filters)
0-20 mA
4-20 mA
Voltage accuracy
(4 and 17 Hz filters)
0-5 V
0-10 V
±10 V
Repeatability (at 25 ºC)
0-5 V, 0-10 V, ±10 V
2085sc-IF16V
0-20 mA, 4-20 mA
2085sc-IF16C
1
These filters do not reject 50/60 Hz. Repeatability for these filters is strongly dependent on how much 50/60 Hz noise
is in the system.
Chapter 1: Module Overview
5% to 85%, non-condensing
10 Hz to 500 Hz, 2 G, 0.030 max peak-to-peak
25 g, peak acceleration, 11±1 ms pulse, half sine
25 g peak acceleration, 11±1 ms pulse, half sine; 35 g for panel
mount.
Meets Pollution Degree 2 requirements.
6 kV Indirect (Coupling Plate)
6 kV Contact Discharge (to points of initial contact)
8 kV Air Discharge (to points of initial contact)
10 V/M with 1 kHz sine-wave 80% AM from 80...6000 MHz
10 V/M with 200 Hz square-wave 50% Pulse 100% AM at 900
MHz
10 V/M with 200 Hz square-wave 50% Pulse 100% AM at 1890
MHz
16 current or voltage differential input channels
Current (IF16C):
0-20 mA, 4-20 mA
Voltage (IF16V):
0-5 V, 0-10 V, ±10 V
4 Hz, 17 Hz, 62 Hz, 470 Hz
Error at 25 °C, Max
±20 µA
±20 µA
Error at 25 °C, Max
±3 mV
±10 mV
±10 mV
4 Hz filter
17 Hz filter
±1.0 mV
±2 mV
±2 µA
±3 µA
Value
Error over -20 °C to 65 °C, Max
±50 µA
±50 µA
Error over -20 °C to 65 °C, Max
±6 mV
±20 mV
±20 mV
60 and 470 Hz filters
±3 mV
±10 µA
User's Manual Pub. 0300306-02 Rev. B
1-3
