Input Description
REACH
Dimensions
Table 1-2. EMC Specification Table
Environmental Tests
Radiated Emissions
Conducted Emissions
ESD immunity
(Performance Criteria B)
Radiated RF immunity
(Performance Criteria A)
EFT/B immunity
(Performance Criteria B)
Surge transient immunity
(Performance Criteria B)
Conducted RF immunity
(Performance Criteria A)
Magnetic Field
(Performance Criteria A)
AC Mains Voltage Dips,
Interruptions and Variations
Chapter 1: Module Overview
Meets European REACH 7 requirements.
110 mm × 87 mm × 51 mm (plastics)
110 mm × 89 mm × 51 mm (with RTBs installed.)
Test Level Limits
(Enclosure) Class A, 30 MHz – 1 GHz
Group 1, Class A (AC Mains), 150 kHz – 30 MHz
6 kV Indirect (Coupling Plate)
6 kV Contact Discharge (to points of initial contact)
8 kV Air Discharge (to points of initial contact)
10 V/M with 1 kHz sine-wave 80% AM from 80...6000 MHz
10 V/M with 200 Hz square-wave 50% Pulse 100% AM at
900 MHz
10 V/M with 200 Hz square-wave 50% Pulse 100% AM at
1890 MHz
Signal Ports:
± 2 kV @ 5 kHz for 5 minutes, Criteria B
Power Ports:
±2 kV at 5 kHz for 5 minutes, Criteria B
Signal Ports:
±2 kV line-earth {CM}at 2Ω on shielded ports
Power Ports
±2 kV CM at 12 Ω
±1 kV DM at 2 Ω
10 V RMS with 1 kHz sine wave 80% AM from 150
kHz...80 MHz on signal and power ports
30 Arms/m
Follow the 61000-4-11.
Value
User's Manual Pub. 0300306-02 Rev. B
1-5
