3-16
Chapter 3: Configuring the 2085sc-IF16 Using CCW
Name
Bit
Range Type
Bit 8 – 9
ADC Filter
Bit 10 – 11
(unused)
Bit 12 – 15
Word
Name
Offset
Process Alarm Low
0
Value
1
Process Alarm High
Value
Word
Name
Input 0
Ch 0 Data
Input 1
Ch 1 Data
Input 2
Ch 2 Data
Input 3
Ch 3 Data
Input 4
Ch 4 Data
Input 5
Ch 5 Data
Input 6
Ch 6 Data
User's Manual Pub. 0300306-02 Rev. B
Description
IF16C:
0: 4 to 20 mA (default)
1: 0 to 20 mA
2: (invalid)
3: (invalid)
IF16V:
0: -10 to +10 V (default)
1: 0 to 10 V
2: 0 to 5 V
3: (invalid)
0: 16.7 Hz (default)
1: 4.17 Hz
2: 62 Hz
3: 470 Hz

3.5.8 Channel Alarm Values Struct

The structure definition for each 'Ch n Alarm Values' in the Configuration
Assembly table is defined as follows. If process alarms are disabled, their values
must be 0:
Type
INT
INT

3.5.9 Input Assembly

The input array is organized as follows:
Type
INT
INT
INT
INT
INT
INT
INT
Length
Description
(Words)
1
Channel low alarm value
1
Channel high alarm value
Length
Description
(Words)
1
Analog Channel Data Channel 0
1
Analog Channel Data Channel 1
1
Analog Channel Data Channel 2
1
Analog Channel Data Channel 3
1
Analog Channel Data Channel 4
1
Analog Channel Data Channel 5
1
Analog Channel Data Channel 6
