Bit
Name
Bit 15
Module Fault
Word
Bit
Output 0
Bit 0
Bit 1
Bit 2
Bit 3
Bit 4
Bit 5
Bit 6
Bit 7
Bit 8
Bit 9
Bit 10
Bit 11
Bit 12
Bit 13
Bit 14
Chapter 3: Configuring the 2085sc-IF16 Using CCW
Description
0: No Fault
1: Fault
This bit is set if any of the above bits are set or if any channel
has its fault bit set.

3.5.12 Output Assembly Words

The Output array is organized as follows:
Name
Ch 0 Process Alarm High Latch Clear
Ch 0 Process Alarm Low Latch Clear
Ch 1 Process Alarm High Latch Clear
Ch 1 Process Alarm Low Latch Clear
Ch 2 Process Alarm High Latch Clear
Ch 2 Process Alarm Low Latch Clear
Ch 3 Process Alarm High Latch Clear
Ch 3 Process Alarm Low Latch Clear
Ch 4 Process Alarm High Latch Clear
Ch 4 Process Alarm Low Latch Clear
Ch 5 Process Alarm High Latch Clear
Ch 5 Process Alarm Low Latch Clear
Ch 6 Process Alarm High Latch Clear
Ch 6 Process Alarm Low Latch Clear
Ch 7 Process Alarm High Latch Clear
Description
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
User's Manual Pub. 0300306-02 Rev. B
3-19
