operation are provided below.
A 2085sc-IF16 module with Version 1.1 firmware uses a single, green OK LED
to show power or module operational status.
When startup is completed, and all internal tests have passed, the LED is solid
GREEN. If the LED remains off, there is an error with the module: it may not
have power, or the module failed to pass the self-test.
Table 1-4 LED Blink Codes Table for Firmware 1.1
Indicator
State
Off
Solid
Green
Module OK
LED Status
Blinking
Green
A 2085sc-IF16 module with Version 2.1 firmware uses a single, green OK LED
to show power or module operational status:
•
When startup is completed, and all internal tests have passed, the LED is
solid GREEN. This indicates RUN mode.
If the LED remains off, there is an error with the module: it may not have
•
power or failed to pass the self-test.
Any time the system is not in Run mode (and showing no faults), the
•
LED blinks rapidly, indicating the module is Offline. All inputs and
outputs are disabled in this instance.
The LED identifies different conditions using specific, numeric, blink patterns.
The module blinks a specific number of times, pauses, and then repeats the same
blink pattern indefinitely. Blink codes are shown in the following table.
Chapter 1: Module Overview
Description
No power applied to device or the module may have
failed to pass its self-test.
RUN mode. Module has power and passed self-test.
No action is required.
LED blink status:
1. Internal use only.
2. Internal use only.
3: Internal use only.
4: Internal use only.
5: Indicates ADC communication error.
6: Indicates Watchdog reset.
User's Manual Pub. 0300306-02 Rev. B
1-7
