3-20 Chapter 3: Configuring the 2085sc-IF16 Using CCW
Word Bit
Bit 15
Output 1 Bit 0
Bit 1
Bit 2
Bit 3
Bit 4
Bit 5
Bit 6
Bit 7
Bit 8
Bit 9
Bit 10
Bit 11
Bit 12
Bit 13
Bit 14
Bit 15
User's Manual Pub. 0300306-02 Rev. B
Name
Ch 7 Process Alarm Low Latch Clear
Ch 8 Process Alarm High Latch Clear
Ch 8 Process Alarm Low Latch Clear
Ch 9 Process Alarm High Latch Clear
Ch 9 Process Alarm Low Latch Clear
Ch 10 Process Alarm High Latch
Clear
Ch 10 Process Alarm Low Latch
Clear
Ch 11 Process Alarm High Latch
Clear
Ch 11 Process Alarm Low Latch
Clear
Ch 12 Process Alarm High Latch
Clear
Ch 12 Process Alarm Low Latch
Clear
Ch 13 Process Alarm High Latch
Clear
Ch 13 Process Alarm Low Latch
Clear
Ch 14 Process Alarm High Latch
Clear
Ch 14 Process Alarm Low Latch
Clear
Ch 15 Process Alarm High Latch
Clear
Ch 15 Process Alarm Low Latch
Clear
The bits in output words 0 and 1 are written during run mode to clear any latched
low or high process alarms. The alarm is unlatched when the Latch Clear bit is
set (1) and the alarm condition no longer exists. If the alarm condition persists,
then the Latch Clear bit has no effect until the alarm condition no longer exists.
You need to keep the Latch Clear bit set (1) until the corresponding Process
Description
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
0: Normal Operation
1: Clear Alarm Latch
