3-26
Chapter 3: Configuring the 2085sc-IF16 Using CCW
Fault Code
Extended Fault Code
0×305
0×306
Fault Code
Extended Fault Code
0×410-41F
0×420-42F
0×430-43F
0×440-44F
0×F2Bz
8
0×450-45F
z indicates the slot number of the expansion I/O. If z=0, then the slot number cannot be identified
8
User's Manual Pub. 0300306-02 Rev. B
Error Description
Unused by the 2085sc-IF16
PLC communications error

3.6.7 Module Specific Channel Configuration Errors

If you set invalid configuration values in the PLC, the CCW will generate a high-
level configuration fault. The connection status will be defaulted and
disconnected.
Error Description
Invalid Input Range
Check the Range Type setting in the Channel
Configuration data.
Invalid Input ADC Filter
Check the ADC Filter setting in the Channel
Configuration data.
Invalid Input Data Format
Check the Data Format setting in the Channel
Configuration data.
Alarm Not Enabled
Check the Channel Enable, Process Alarm Enable,
and Process Alarm Latch bits in the Channel
Configuration data. This error occurs if the channel
is enabled and the Process Alarm Latch bit is set,
but the Process Alarm Enable bit is not set.
Invalid Alarm Data
Check the Process Alarm Low Value and Process
Alarm High Value for legal ranges. If the module
receives any of the following illegal data, this error
is detected:
Range Max less than AHV
Range Min greater than ALV
AHV less than or equal to ALV
ALV is the Process Alarm Low Value
AHV is the Process Alarm High Value
Range Max and Range Min are the full-scale values
for the selected Input Range and Input Data
Formats as defined in the Range Limits table.
