Section 3.5
Software Information
Parameter
Vendor ID
Product Type
Product Code
Series Rev (1.1)
Series Rev (2.1)
Module Catalog String
Chapter 3: Configuring the 2085sc-IF16 Using CCW

3.5.1 Software Versioning

The software version tracks major and minor revisions for end users.
The shipped software version begins at version 1.1.
Once released, the major revision is typically incremented if new features are
introduced to the product. Otherwise only the minor revision is incremented.

3.5.2 Software Updates

In-field updating of the software by the end user is not supported.

3.5.3 Startup and Factory Default Conditions

After the module boots and before the initial configuration is received, the
modules run with default configurations as specified in the Configuration
Assembly.
The default configuration for the IF16C is for all channels enabled in the 4-
20 mA range with the 17 Hz filter in Engineering ×1 units.
The default configuration for the IF16V is for all channels enabled in the ±10
V range with the 17 Hz filter in Engineering ×1 units.
Module Identity
The following values will be stored in the Vendor ID, Product_Type,
Product_Code, Series_Rev, and Mod_Features arrays:
2085sc-IF16C
58 (Spectrum Controls)
10 (Analog) ) [0×0A]
112 [0×70]
0×C420
0×C440
2085sc-IF16C

3.5.4 Connection Types and Assembly Sizes

The size of each assembly is listed in the table below. Each word is 2 bytes.
These values are stored in the Mod_Size array:
Table

Configuration Assembly

Input Assembly
Output Assembly
3.5.5 Configuration Assembly
The Configuration Assembly table (Mod_Config array) is organized as follows:
2085sc-IF16V
58 (Spectrum Controls)
10 (Analog) ) [0×0A]
111 [0×06F]
50208 (First release revision is
1.1)
50240 (Second release revision
is 2.1)
2085sc-IF16V
Size (words)
48
25
5
User's Manual Pub. 0300306-02 Rev. B
3-13
