SPC Series Solar Pump Inverter
Field Symbol
SPC
2K2
TR
2
6
H

2.4 Product specifications

Model
Output power
(kW)
DC input
Max. DC input
voltage (V)
Start voltage (V)
Min. working
voltage (V)
Recommended
DC input voltage
range (V)
Recommended
MPP voltage (V)
AC output
Output voltage
(V)
Output
frequency (Hz)
Control performance
Control mode
Motor type
Description
Product series
①
abbreviation
②
Rated power
③
Technical type
④
Output voltage class
Ingress protection (IP)
⑤
rating
⑥
Configuration frame
SPC2K2TR20
SPC2K2TR26-S
SPC2K2TR26-H
2.2
450
120
70
200–400
330
0–230
0–400
V/F (SVPWM), SVC
Asynchronous motor (AM) and synchronous motor (SM)
Abbreviation of solar pump controller
The rated power is 2.2kW.
TR: 3PH
2: 3PH 220V
4: 3PH 380V
0: IP00
6: IP65
IP65 model type.
H: High performance
S: Standard
SPC004TR40
SPC004TR46-S
SPC004TR46-H
4
800
250
200
300–750
580
0–400
0–400
-6-
Product overview
Content
SPC7K5TR40
SPC7K5TR46-S
SPC7K5TR46-H
7.5
800
250
200
300–750
580
0–400
0–400
