SPC Series Solar Pump Inverter
Fault code
OL3
ETH1
ETH2
dEu
STo
LL
A-LS
Fault type
Electronic
overload fault
To-ground
short-circuit fault 1
To-ground
short-circuit fault 2
Speed deviation
fault
Mal-adjustment
fault
Electronic
underload fault
Weak-light
pre-alarm
Possible cause
The inverter reports
overload pre-alarm
according to the
setting.
The output of the
inverter is short
circuited to the
ground.
There is a fault in the
current detection
circuit.
The load is too heavy
or stalled.
SM control
parameters are set
incorrectly.
Autotuned
parameters are not
accurate.
The inverter is not
connected to the
motor.
The inverter reports
underload pre-alarm
according to the
setting.
The sunlight is weak
or the PV module
configuration is
insufficient.
-53-
Fault diagnosis and solution
Solution
Check the load and the
overload pre-alarm
points.
Check whether the
motor wiring is normal.
Replace the Hall
device.
Change the main
control board.
Check the load and
increase the detection
time if the load is
normal.
Check whether control
parameters are set
correctly.
Check the load and
ensure the load is
normal.
Check whether control
parameters are set
correctly.
Increase the
mal-adjustment
detection time.
Check the load and the
underload pre-alarm
points.
The device will
automatically run when
the light is sufficient.
Check whether the PV
module configuration is
sufficient.
