INVT SPC Series Operation Manual page 18

SPC Series Solar Pump Inverter
No. Name
Unit
2
indicator
Digital
3 display
zone
4 Keys
Unit displayed currently
Five-digit LED displays various monitoring data and alarm codes such as
the frequency setting and output frequency.
Display Means Display Means Display Means Display Means
0
0
4
4
8
8
c
C
H
H
n
n
5
S
.
.
Programming
PRG
ESC
key
Confirmation
DATA
ENT
key
Up key
Down key
Right-shifting
SHIFT
key
Run key
RUN
Stop/
STOP
RST
Reset key
Description
Blinking: in pre-alarm state
On: in fault state
Hz
RPM
A
%
V
1
1
5
5
9
9
D
D
i
I
o
o
t
t
-
-
Press it to enter or exit level-1 menus or delete a
parameter.
Press it to enter menus in cascading mode or
confirm the setting of a parameter.
Press it to increase data or move upward.
Press it to decrease data or move downward.
Press it to select display parameters rightward in
the interface for the inverter in stopped or
running state or to select digits to change during
parameter setting.
Press it to run the inverter when using the
keypad for control.
Press it to stop the inverter that is running. The
function of this key is restricted by P07.04. In
-14-
Keypad operation guidelines
Frequency unit
Rotation speed unit
Current unit
Percentage
Voltage unit
2
2
6
6
A
A
E
E
L
L
P
P
U
U
3
3
7
7
B
B
F
F
N
N
r
r
V
v
