Removing the Optical (CD/DVD) Device

1. Turn off the computer, remove the battery
2. Remove the screw at point
1
3. Insert the new device and carefully slide it into the computer (the device only fits one way. DO NOT FORCE IT; The
screw holes should line up.
4. Insert the new device and replace the optical device screw
5. Reconnect the fan cable before replacing the bay cover (
6. Replace the bay cover and screws.
7. Restart the computer to allow it to automatically detect the new device.
a.
1
(page 2 - 5), and the CPU/RAM bay cover
, and use a screwdriver to carefully push out the optical device at point
.
1
5
b.
(page 2 - 10)
in Figure 6 on page 2 - 10).
3
Removing the Optical (CD/DVD) Device 2 - 17
Disassembly
Figure 13
Optical Device
.
Removal
.
2
a. Remove the cover and
locate the screw.
b. Remove the screw and
push the optical device
out off the computer at
point 2 and remove the
optical device.
2
3. Optical Device
• 1 Screw
