Disassembly

Removing the Optical (CD/DVD) Device Drive

Figure 6
HDD Assembly
1. Turn off the computer, and turn it over and remove the battery
Removal
2. Locate the ODD cover and remove the screw
3. Use a screwdriver to carefully push out the optical device at point
a. Remove the screw.
4. Reverse the process to install the new device.
b. Remove the cover.
c. Push the device out.
d. Remove the device. a.
c.
2. ODD Cover
4. Optical Device
• 1 Screw
2 - 10 Removing the Optical (CD/DVD) Device Drive
All manuals and user guides at all-guides.com
1
(page 2 - 5).
and cover .
2
1
.
3
b.
2
d.
4
3
