Recorder Connections
The functions of the standard connectors on the 130-SMHR/9 faceplate are as follows:
Channels 4-6
Connection
Channels 7-9
Connection
Reftek Systems Inc.
REF TEK 130-SMHR/9 Users Guide
98060-00-UG
Relays for External
Alarm Notification
Ethernet Optional
External Modem
Optional Internal
Modem (POTS)
130-GPS
Local Serial
Connection
5/6/2021
15V
Power
5
