Recorder Connections - Reftek 130-SMHR-C User Manual

Rev J
RT530-B01 Lid
RT649 –B05 A/D Ch 1-3 and
Opt.:
RT649 –B06 A/D for Ch 4-6
RT506-B01 CPU
RT570-B01 Flash
147A-01/3/INT/SM
Accelerometer

Recorder Connections

The functions of the standard connectors on the 130-SMHR-C faceplate are as follows:
Internal Modem
(POTS)
Optional
Channels 4-6 Sensor
Connection
4
REF TEK 130-SMHR-C Users Guide
96480-00-UG
Relays for External
15V Power
Alarm Notification
Ethernet
130-GPS
5/6/2021
Optional Internal
12V Battery
Optional External 12V
Battery
Local
Serial Connection
Reftek Systems Inc.
