018:08:58:54 Channel:Offset
Reports the DAS A/D offset in hex counts for channels 4 - 6. This offset is user selectable It is factory set for
terminated input to center around zero counts. RT505 A/D inherent offset is approximately 123,000 decimal
counts.
018:08:58:54 BOARD $01: RT0520D S/N 0753 0 (LID) Marker OK
Reports the DAS RT520 LID board serial number.
018:08:58:54 BOARD $02: RT0506D S/N 0817 1 (CPU) Marker OK
Reports the DAS RT506 CPU board serial number.
018:08:58:54 BOARD $10: RT0505D S/N 0759 1 (ATD) Marker OK
Reports the DAS RT505 A/D board (Channels 1-3) serial number.
018:08:58:54 BOARD $11: RT0505D S/N 0754 1 (ATD) Marker OK
Reports the DAS RT505 A/D board (Channels 4-6) serial number.
018:08:58:54 CPU FPGA: RT0506A1A (11FA1821) test version 1
Reports the DAS RT506 CPU SPROM version.
018:08:58:54 AD1 FPGA: RT0505A1C (11F91C03) test version 32
Reports the DAS RT505 A/D (Channels 1-3) SPROM version.
018:08:58:54 AD2 FPGA: RT0505A1C (11F91C03) test version 32
Reports the DAS RT505 A/D (Channels 4-6) SPROM version.
018:08:59:04 Network layer is UP!
Indicates the 130 DAS/RTPD network is up. Full Stack has been negotiated.
018:08:59:04 RTP: Stopped by event Open
The DAS and the RTPD server use the TCP/IP stack to sync. If the connection is broken or a re-sync is initiated the
DAS reports this message. It indicates the DAS and RTPD are negotiating a link or the DAS has lost its connection to
RTPD and will attempt to re-sync.
357:02:53:46 MEMORY USED=00006, AVAILABLE=02298, TOTAL=02304
Reports the RAM memory usage in the 130 DAS.
Reftek Systems Inc.
REF TEK 130-SMHR/9 Users Guide
98060-00-UG
4:$0001DF3A 5:$0001E00F 6:$0001DE49
