Channel 4-6 Connector - Reftek 130-SMHR/9 User Manual

Rev A

Channel 4-6 connector

The channel 4-6 connector on the 130-SMHR/9 provides inputs for an external sensor.
Recorder 130
Faceplate Pin
Channel 4-6 A
PT0A1419S B
C
D
E
F
G
H
J
K
L
M
N
P
R
S
T
U
V
Note: 1 = Hardware user selectable to +15 Volts or +24 Volts (See Section 2.5)
Note: 2 = Protected by self resetting fuse
Note: 3 = See Section 2.5 for channel connection information
Note: 4 = Open Collector, pulls to Ground
Note: 5 = Open Collector, pulls to + 5 Volts
Note: 6 = Functions provided by Optional RT527 Sensor Control Board
Note: 7 = Also can be activated by Sensor test command to test REF TEK 131
installed
10
REF TEK 130-SMHR/9 Users Guide
98060-00-UG
Name Dir
CH4+ In
CH4- In
CH5+ In
CH5- In
CH6+ In
CH6- In
AGND In
PWR Out
PGND -
CalEn- 456 Out
CalEn+ 456 Out
Center- 456 Out
CalSig 456 Out
Aux4 In
Aux5 In
Aux 6 In
DGND -
Center+ 456 Out
Sensor ID2 In/Out
Electrical Desc
Channel 4 input +
Channel 4 input -
Channel 5 input +
Channel 5 input -
Channel 6 input +
Channel 6 input -
Analog ground
Sensor power
Power ground
Calibration Enable active
low
Calibration Enable active
high
Center Enable
active low
Calibration signal
Aux (Mass Position)
Channel 4
Aux (Mass Position)
Channel 5
Aux (Mass Position)
Channel 6
Digital ground
Center Enable Active High
Sensor ID
Accelerometers if no RT527 is
