Configure The Modem Initialization String - Reftek 130-SMHR/9 User Manual

Rev A
needs to hang up to force the "power" window to be shut-down and re-established so that the
init string is resent.
1. To set the baud rate enter the following
{PM,92CB,SP,57600
Type
2. The response will be similar to the following example:
}PM,92CB,OK
Note: It is preferred to set the port speed at 19200 to allow for phone noise and the modem buffering to keep up.

Configure the modem initialization string

The IN string must have at least one AT command supplied. If the IN and HU strings are null, then
it is assumed that the modem port has no modem attached. By doing this the external port can
be used in a direct serial mode (presuming the internal modem is not installed).
1. To define the 130-SMHR/9 modem initialization parameters enter the following:
{PM,92CB,IN,ATE0 V0 S0=1
2. The response will be similar to the following example:
}PM,92CB,OK
Reftek Systems Inc.
REF TEK 130-SMHR/9 Users Guide
98060-00-UG
Set the modem baud rate to 57600
Note: This is the Factory Default setting
and is recommended when using the
internal 130-MC modem.
Set the modem initialization string
Auto Answer after 1 ring
Enable Results codes
Echo off
5/6/2021
41
