1 130-SMHR/9 Overview

Introduction

This section describes connections and purpose of the REF TEK 130-SMHR/9.
The 130-SMHR/9 (98060-00) unit is intended for deployment in buildings or other structures such
as a bridge. This design, with an internal tri-axial accelerometer and external connectors for two
external tri-axial accelerometers, is well suited for structural monitoring.

130-SMHR/9 Features

Feature
Communication
Command/Control
Display
Enclosure
Relays
Oscillator
Options

Mating Connectors

Function
Serial
Power
GPS
NET
Channel (x2)
Modem
Relay
Reftek Systems Inc.
REF TEK 130-SMHR/9 Users Guide
98060-00-UG
Description
TCP/IP over Ethernet and Asynchronous Serial
SMCC for command line
Interface allows programming and examination of operating parameters as well as performing
some diagnostic functions
Unit LCD continuously displays state-of-health and status
Larger case for internal battery for backup power
3 Relay closures contacts for external alarm notification
Relay closure parameters are user selectable
Different from SM - Used for internal time keeping
Internal V.90 modem for event trigger, alarm notification and dial-in
Battery Charger - External or internal lead-acid battery
Size of the case allows internal battery (12 VDC sealed lead-acid 12 AmpH) to provide up to 24
hours of backup power.
Mating Connector
PT06SE12-10S
PT06A12-4P
PT06SE12-8P
PT06SE14-19S
PT06SE14-19P
PT06A12-3S
PT06SE14-15S
