System information

290:00:09:07 Using Ethernet RTP Link
The DAS reports datastream parameters require data to be sent via Ethernet to an RTP host setup in the network
parameters.
018:08:58:54 Serial Link K/T MODE: Keep STATE: Keep, LINE MODE: Direct
Reporting Serial PPP parameters. If the link goes down data will be kept locally in RAM or disk.
018:08:58:54 Serial Link LINE SPEED: 19200
Indicates a PPP Serial link will attempt to connect at 19200.
This is a set baud rate for this link.
018:08:58:54 Ethernet Link K/T MODE: Keep STATE: Keep, LINE MODE: Direct
Reports Ethernet setup parameters. If the Link goes down the data will be kept locally in RAM or Disk.
018:08:58:54 Ref Tek 130 v2.1.4R (2003:268)
Reports the DAS firmware version being used.
018:08:58:54 IP: 194.226.112.142
Reports the DAS IP address from network parameters.
Ethernet is reported first and Serial PPP second.
018:08:58:54 Mask: 255.255.255.0
Reports the DAS Mask from network parameters.
Ethernet is reported first and Serial PPP second.
018:08:58:54 Host: 194.226.112.210
Reports the DAS RTPD or Host address from network parameters.
Ethernet is reported first and Serial PPP second.
018:08:58:54 Gate: 194.226.112.125
Reports the DAS Gateway from network parameters. Ethernet is reported first and Serial PPP second.
018:08:58:54 Channel:Offset
Reports the DAS A/D offset in hex counts for channels 1 - 3. This offset is user selectable. It is factory set for a
terminated input to center around zero counts. RT505 A/D inherent offset is approximately 123,000 decimal
counts.
66
REF TEK 130-SMHR/9 Users Guide
98060-00-UG
192.168.1.11
255.255.255.0
0. 0. 0. 0
192.168.1.10
1:$0001DE8A 2:$0001DFF7 3:$0001DDDD
