Rev A
In addition to the CPU control code in the 130-SMHR/9, the 130-SMHR/9 requires that you
download specific parameter information to instruct it exactly how and when to record data and
perform other system functions. REF TEK provides the specific software that instructs the 130-
SMHR/9 how to perform system functions. Communications with the 130-SMHR/9 occurs
through a PC and terminal (with command line control) or using the SMCC interface..
Also REF TEK maintains release notes for each firmware version on its FTP and www.reftek.com
site.

General recorder operation with command line

Communication with the 130-SMHR/9 occurs through a PC and terminal program. Refer to the
130 Command Line Reference for addition help. With the terminal program you can:
•
Set parameters
•
Send parameters to the 130-SMHR/9
•
Start data acquisition
The 130-SMHR/9 collects data based on the series of parameters that you select and implement.
All 130-SMHR/9 units have multiple datastream capability, allowing users a vast array of possible
parameter combinations. You may set the following parameters for each datastream:
•
Which input channel or channels to include
•
Sample rate
•
Data format (recording resolution)
•
Trigger type
The possible values for these parameters, as well as the possible combinations of parameters,
are different for the 130-SMHR/9 with different hardware configurations, different versions of
control firmware, or both. For a comprehensive explanation of your 130-SMHR/9 specific
capabilities and limitations, refer to the REF TEK 130-Command Line - Theory of Operations
manual and individual 130-SMHR/9 board and schematics manuals.
The trigger type selected for a datastream defines the particular mechanism that determines
when the 130-SMHR/9 collects data. The trigger types available on the 130-SMHR/9 are as
follows:
•
Continuous trigger
•
Vote trigger
•
External trigger
Each trigger has its own set of parameters that determines the exact conditions under which the
130-SMHR/9 records data.
Detailed explanations and methods for using all 130-SMHR/9 parameters, including datastreams
and triggers, are provided in subsequent sections in this manual.
REF TEK pre-sets and tests the hardware of each 130-SMHR/9 before you receive the unit to
ensure that it performs as specified. The 130-SMHR/9 does not require hardware adjustments
for normal operations. You may use a 130-SMHR/9 as a stand-alone system, or you may use a
