Internal battery cable
Internal Sensor cable
(Used w/ RT570)
Connector Assembly & Maintenance
To allow you to choose the particular peripherals to use (such as power supply, modem, and
external clock), and suitably locate them, REF TEK does not supply complete cables with your
recorder. Instead, REF TEK supplies a kit that contains the mating connectors that you need to
construct the cables required by your particular peripherals and system configuration. Upon
order, REF TEK will supply any or all of our standard connector cables (as described later). Also,
REF TEK will construct any custom cables your system needs. The standard recorder connector
assembly shows the assembly of the standard type of connector that you will find in your mating
connectors kit. Pin connections are supplied in the first section of the 130-SMHR/9 manual.
When making the connections follow industry standard practices in dressing the cable end,
soldering the connections and applying shrink tubing. The use of self-vulcanizing tape is
preferred to potting the connector since with potting, the connector is no longer field
serviceable.
Note: For additional moisture protection, apply DL-111 inside the top shell to seal against the rubber grommet. The
bottom shell must rotate freely after the top shell has been firmly tightened into the connector body.
58
REF TEK 130-SMHR/9 Users Guide
98060-00-UG
RT530 to internal battery
131-8050 Sensor assembly to RT570 (JP11-JP14)
