Toss parameter:
CAUTION: If the connection goes down, the Toss parameter throws away old data after the
specified Toss time (2 to 99 minutes), until the connection is re -established. Consideration
should be taken to adjust the toss time according to the sample rate so that the toss delay
time expires before the RAM fills causing acquisition to stop.
The following is an example with a verbose response:
{PR,9081,PN
}PR,9081,PN,1,192.168.100.087,255.255.255.000,192.168.100.198
,192.168.100.001,P,T,D,10,20
}VR,9081,
}VR,9081, Network Parameters
}VR,9081, IP: 192:168:100:087
}VR,9081, MASK: 255:255:255:000
}VR,9081, HOST: 192:168:100:198
}VR,9081, GATEWAY: 192:168:100:001
}VR,9081, Power to ENET chip always on
}VR,9081, Data when line down tossed
}VR,9081, Line mode not used
}VR,9081, Port Speed not used
}VR,9081, Line delay: 20
Check the IP Address, Mask, Host, and Gateway Addresses.
Example NET configurations with Ethernet link down and acquisition on:
•
If the unit parameters are set to dump to disk ONLY then there is no effect.
•
If the unit parameters are set to dump to Ethernet and to disk, then the unit will dump the
data to disk when the RAM reaches the dump point (default = 66% full), but the RAM will
not empty until the data is sent out over the Ethernet link or the unit switches to toss mode
and discards the data destined for the NET Port.
•
If the data is being sent only to Ethernet, then the RAM will fill until the toss delay threshold
is reached. Once the Ethernet connection is re-established, the data in RAM will be sent out
the Ethernet port and acquisition will re-start automatically.
CAUTION: There will be only a loss of data while the acquisition state is off

Internal modem port

Each 130-SMHR/9 unit provides an optional internal modem, accessible at the Modem connector
on the 130-SMHR/9 unit's faceplate. This port has the following primary functions and
characteristics:
Reftek Systems Inc.
REF TEK 130-SMHR/9 Users Guide
98060-00-UG
5/6/2021
23
