Gps Connector; Modem Connector; 130-Smhr/9 Net Connector - Reftek 130-SMHR/9 User Manual

Rev A

GPS Connector

The GPS connector allows an external clocking device, such as the REF TEK 130-GPS\01 Global
Positioning System clock to be connected.
Recorder Connector
Faceplate
GPS(Ext Clock) PT0-7A128S

Modem connector

The modem connector provides connections for the 130-SMHR/9 internal modem. The modem
connector is provided in order to connect the internal modem to the Plain-Old-Telephone-
Service.
Recorder Connector
Faceplate
Modem PT0-7A-12-3P

130-SMHR/9 Net Connector

Communications between the 130-SMHR/9 and a remote system using either external TCP/IP
and/or an optional external modem occur across the 130-SMHR/9 NET connector. The cable has
two connectors to allow two connections, one for Ethernet and one for serial communications.
The internal modem must be removed before using an external modem. See Section 2 in this
manual for a procedure on removing the internal modem.
CAUTION: A 130-SMHR/9 is shipped pre-configured with a default IP address. Be sure to
change this address before connecting the 130-SMHR/9 to an Ethernet port. Any IP
addresses on one of the same subnets, as the 130-SMHR/9 unit, may connect using FTP
and/or the command socket. However, the 130-SMHR/9 unit restricts the external IP
addresses from which it will accept connections, to the equivalent of a Class C subnet
containing the RTP host. If no RTP host is set for an interface, no connections can be
established to the unit from outside its subnet.
The 130-SMHR/9 uses a 10BaseT Ethernet chip. The 130-SMHR/9 Ethernet port may not
work when connected to all 100BaseT and some 10/100BaseT Ethernet hubs.
4
Volts = Controlled by software and protected by self resetting fuse
Reftek Systems Inc.
REF TEK 130-SMHR/9 Users Guide
98060-00-UG
DAS Pin Desc Electrical Desc
Pin
A GPS 1Hz Input Pulse
B DGND PWR/Signal GND
C GPS RX Output RS232
D DGND PWR/Signal GND
E GPS TX Input RS232
F PWR 12V 12 Volts Output
G GPS RST Output Pulse
H IRIGE 5 Volts Output1
DAS Pin Desc Electrical Desc
Pin
A TIP Telephone Line
B RING Telephone Line
C X No Connection
5/6/2021
Voltage Range
0-5 Volts
±5 Volts
±12 Volts
4
10-15 Volts
0-3.3 Volts
0-5 Volts
Voltage Range
7
