Relay connector

The relay connector on the 130-SMHR/9 provides three relay closures for certain software set
able alarm conditions.
Recorder Connector
Faceplate
Relay PT0-7A-14-15P
Note: There is an optional jumper (JP3 located near the relay connector) that can be installed on the RT630 Lid
board in order to set the three provided relays as normally energized.
Reftek Systems Inc.
REF TEK 130-SMHR/9 Users Guide
98060-00-UG
DAS Pin Desc Electrical Desc
Pin
A NO Relay 1 Normally Open Contact
B COM Relay 1 Common Contact
C NC Relay 1 Normally Closed Contact
D X No Connection
E NO Relay 2 Normally Open Contact
F COM Relay 2 Common Contact
G NC Relay 2 Normally Closed Contact
H X No Connection
J NO Relay 3 Normally Open Contact
K COM Relay 3 Common Contact
L NC Relay 3 Normally Closed Contact
M X No Connection
P X No Connection
R X No Connection
N X No Connection
5/6/2021
Voltage
Range
0-120V AC 0-
30V DC
0-120V AC
0-30V DC
0-120V AC
0-30V DC
9
