Overview
1
1.1
1.2
1.3
4/48
Downloaded from
Elcodis.com
electronic components distributor
Overview
Order code
To order the STM32F103ZGT6GT6 evaluation board, use the order code STM3210E-EVAL.
Features
Three 5 V power supply options: power jack, USB connector or daughterboard
Boot from user Flash, system memory or SRAM
I2S audio DAC, stereo audio jack
128 Mbyte MicroSD Card
Both A and B type smartcard support
64 or 128 Mbit serial Flash, 512 Kx16 SRAM, 512 Mbit or 1 Gbit NAND Flash and 128
Mbit NOR Flash
I2C/SMBus compatible serial interface temperature sensor
Two RS-232 channels with RTS/CTS handshake support on one channel
IrDA transceiver
USB2.0 full speed connection
CAN2.0A/B compliant connection
Inductor motor control connector
JTAG and trace debug support
240x320 TFT color LCD
Joystick with 4-direction control and selector
Reset, wakeup, tamper and user buttons
4 color LEDs
RTC with backup battery
Demonstration software
Demonstration software is preloaded in board's Flash memory for easy demonstration of the
device peripherals in stand-alone mode. For more information and to download the latest
version available, please refer to the STM3210E-EVAL demonstration software available
from www.st.com
To use the STM3210E-EVAL evaluation board, you must have the demonstration software
version 1.1 or later. If the version installed on your evaluation board is earlier than version
1.1, you must download the latest version from www.st.com.
TM
Doc ID 14220 Rev 5
UM0488
