Table 24.
Pin #
50
52
54
56
58
60
62
64
66
68
70
Downloaded from Elcodis.com electronic components distributor
Daughterboard extension connector CN11 (continued)
Description Alternative function
GND -
PC5 MC
PA7 MC/SPI_MOSI/QST
PA5 SPI_CLK/DAC_LIN/QST
PA3 MC/USART2_RX
PA2 MC/USART2_TX
-
PC2 MC/BNC2
PC0 MC
- -
GND -
How to disconnect from function block on
STM3210E-EVAL board
-
Disconnect STM3210E-EVAL evaluation board from
motor power drive board.
Disconnect STM3210E-EVAL evaluation board from
motor power drive board and QST board.
Disconnect STM3210E-EVAL evaluation board from
QST board.
Remove R68.
Disconnect STM3210E-EVAL evaluation board from
motor power drive board.
Remove R29.
Disconnect STM3210E-EVAL evaluation board from
motor power drive board.
Disconnect STM3210E-EVAL evaluation board from
motor power drive board.
Disconnect analog signal from BNC2.
Disconnect STM3210E-EVAL evaluation board from
motor power drive board.
Remove C7 & R63.
-
-
