Board function overview
The STEVAL-ILL028V1 demonstration board features:
●
Three STP1612PW05 (QFN24 4 x 4 mm) connected to 16 RBG LEDs
●
16 RGB high brightness LEDs
●
One STM32 microcontroller using internal HS oscillator
●
An ST1S10: a high-efficiency switching DC-DC power supply
●
7.5 - 18 V DC power supply with undifferentiated polarity and overvoltage protection
●
DC input current 0.7 A max., standard supply connector
●
LED current regulation
●
The board can be controlled by 3 buttons, a knob and a reset/back button
●
Test point for each main signal
●
Microcontroller firmware update through JTAG interface
●
Error LED and overtemperature LED for each LED driver
●
3 jumpers to disconnect the LEDs from the driver to test the error detection mode
●
3 jumpers to enable LED shortage from the driver to test the error detection mode
●
Mini USB to connect the board to a PC
The board is delivered with a firmware allowing to evaluate the board features in standalone
and nonstandalone mode:
●
LED diagnostic
●
Adjustable brightness of each LED
●
Adjustable color of each LED
●
Animated text
●
