Table 23.
Pin #
41
43
45
47
49
51
53
55
57
59
61
63
65
67
69
2
4
6
8
10
12
14
16
18
20
22
24
26
Downloaded from Elcodis.com electronic components distributor
Daughterboard extension connector CN10 (continued)
Description Alternative function
PB4 Debug_TRST/MC
PB6 I2C_SCL/QST
PB8 CAN_RX
PE0 FSMC_BLN0
D5V -
PE4 Trace_D1/FSMC_A20
PE6 Trace_D3/FSMC_A22
PC14 OSC32_IN
PF0 FSMC_A0
GND -
PF2 FSMC_A2
PF4 FSMC_A4
PF6 LD2
PF8 LD4
+3V3 -
PC6 Smartcard/MC/I2S_MCK
PC8 MicroSDcard_D0/MC
PA8 MCO/LCD_backlight/QST
PA10 USART1_RX
GND -
PA11 USB_DM
PA13 Debug TMS
PA15 Debug TDI
PC11 IrDA_RX/MicroSDcard_D2
PC12 MicroSDcard_CLK
PD1 FSMC_D3
PE1 FSMC_BLN1
PD3 Joystick_Down
How to disconnect from function block on
STM3210E-EVAL board
Disconnect STM3210E-EVAL evaluation board from
motor power drive board.
Keep JP19 on open.
Disconnect STM3210E-EVAL evaluation board from
QST board.
Remove R32.
-
-
-
-
Remove R135, Keep JP9 (solder bridge) on close.
-
-
-
-
Remove R96.
Remove R98.
-
Disconnect STM3210E-EVAL evaluation board from
motor power drive board.
Keep JP15 on open.
Disconnect STM3210E-EVAL evaluation board from
motor power drive board.
Remove SD Card from MicroSD Card connector.
Disconnect STM3210E-EVAL evaluation board from
QST board.
Remove R36.
-
Remove R81.
-
-
Remove SD Card from MicroSD Card connector.
Remove R89.
Remove SD Card from MicroSD Card connector.
-
-
Remove R100.
