Development and debug support

The two debug connectors available on the STM3210E-EVAL evaluation board are:
CN9: standard 20-pin JTAG interface connector, compliant with ARM7/9 debug tools.
CN7: SAMTEC 20-pin connector FTSH-110-01-L-DV for both SWD and Trace,
compliant with ARM CoreSight debug tools.

Display and input devices

The 240x320 TFT color LCD connected to bank1 NOR/PSRAM4 of FSMC interface of the
STM32F103ZGT6 and four general purpose color LEDs (LD 1,2,3,4) are available as
display devices. A 4-direction joystick with selection key, general purpose button (B4),
wakeup button (B2) and tamper detection button (B3) are available as input devices.
The jumper JP4 should be kept open to enable the wakeup button B2 which shares the
same I/O with USART2 and motor control connector.
The STM3210E-EVAL evaluation board also supports a second optional 122x32 graphic
LCD that can be mounted on the U18 connector. By default, the graphic LCD is not present.
Table 12. LCD modules
TFT LCD CN16 (default)
Pin on
Description
CN16
1 CS
2 RS
3 WR/SCL
4 RD
5 RESET
6 PD1
7 PD2
8 PD3
9 PD4
10 PD5
11 PD6
12 PD7
13 PD8
14 PD10
15 PD11
16 PD12
17 PD13
18 PD14
Hardware layout and configuration
Graphic LCD U18 (optional)
Pin on
Pin connection
U18
CS of Bank3 of
1 Vss
FSMC
FSMC_A0 2 Vcc
FSMC_NWE 3 VO
FSMC_NOE 4 CLK
RESET# 5 SID
FSMC_D0 6 CS
FSMC_D1 7 A
FSMC_D2 8 K
FSMC_D3
FSMC_D4
FSMC_D5
FSMC_D6
FSMC_D7
FSMC_D8
FSMC_D9
FSMC_D10
FSMC_D11
FSMC_D12
Doc ID 14220 Rev 5
Description Pin connection
GND
3.3V
-
PA5
PA7
PF10
+5V
GND
