Connectors
3.8
Table 23.
Pin #
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
20/48
Downloaded from Elcodis.com electronic components distributor

Daughterboard extension connectors CN10 and CN11

Two 70-pin male headers CN10 and CN11 can be used to connect a daughterboard or
standard wrapping board to the STM3210E-EVAL evaluation board. All total 112 GPI/Os are
available on it. The space between these two connectors and the position of power, GND
and RESET pins (marked in gray in
allows to develop common daughterboards for several evaluations boards. The standard
width between CN10 pin1 and CN11 pin1 is 2700 mils (68.58 mm). This standard is
implemented on the majority of evaluation boards.
Each pin on CN10 and CN11 can be used by a daughterboard after disconnecting it from
the corresponding function block on the STM3210E-EVAL evaluation board, as described in
Table 23 and Table 24.
Daughterboard extension connector CN10
Description Alternative function
GND -
PC7 MC/Smartcard
PC9 MicroSD Card
PA9 UASRT1_TX
PA0 MC/Wakeup/USART2_CTS
- -
PA12 USB_DP
PA14 Debug_TCK
PC10 IrDA_TX/MicroSDcard_D2
GND -
PD0 FSMC_D2
PE2 Trace_CLK/FSMC_A23
PD2 MicroSDcard_CMD/MC
PD4 FSMC_OEN
PD6 FSMC_WAITN
PD7 FSMC_EBAR0
PG10 FSMC_EBAR2
PG12 FSMC_EBAR3
PG14 Joystick_Left
GND -
Table 23 and Table 24) are defined as a standard which
How to disconnect from function block on
STM3210E-EVAL board
-
Disconnect STM3210E-EVAL evaluation board from
motor power drive board.
Keep JP16 on open.
Remove SD Card from MicroSD Card connector.
-
Keep JP4 on open.
-
Remove R82.
-
Remove SD Card from MicroSD Card connector.
-
-
-
Disconnect STM3210E-EVAL evaluation board from
motor power drive board.
Remove SD Card from MicroSD Card connector.
-
-
Remove R22.
Remove R15.
Remove R77.
Remove R102.
-
Doc ID 14220 Rev 5
UM0488
