STMicroelectronics STM3210E-EVAL User Manual page 22

Connectors
Table 23.
Pin #
28
30
32
34
36
38
40
42
44
46
48
50
52
54
56
58
60
62
64
66
68
70
22/48
Downloaded from Elcodis.com electronic components distributor
Daughterboard extension connector CN10 (continued)
Description Alternative function
PD5 FSMC_WEN
GND -
PG9 FSMC_EBAR1
PG11 -
PG13 Joystick_Right
PG15 Joystick_Up
PB3 Debug_TDO
PB5 MC/QST/Temperature sensor
PB7 I2C_SDA/QST
PB9 CAN_TX
3V3 -
GND -
PE3 Trace_D0/FSMC_A19
PE5 Trace_D2/FSMC_A21
PC13 Anti-tamper button
PC15 OSC32_OUT
PF1 FSMC_A1
PF3 FSMC_A3
PF5 FSMC_A5
PF7 LD3
PF9 LD5
GND -
How to disconnect from function block on
STM3210E-EVAL board
-
-
Remove R21.
-
Remove R103.
Remove R104.
-
Disconnect STM3210E-EVAL evaluation board from
motor power drive board and QST board.
Remove R46.
Disconnect STM3210E-EVAL evaluation board from
QST board.
-
-
-
-
-
Remove R111.
Remove R39, Keep JP10 (solder bridge) on close.
-
-
-
Remove R97.
Remove R99.
-
