1 Overview
1.1

Features

● Four 5 V power supply options: Power jack, ST-LINK/V2 USB connector, user USB
connector or daughterboard
● Audio jack connected to I2S DAC, or STM32L152ZDT6 internal DAC
● Microphone connected to ADC using integrated op amp as amplifier
● 2 GByte (or more) MicroSD Card on SDIO interface
● Temperature sensor and RF EEPROM on I2C compatible serial interface
● RS-232 interface configurable for communication or Flashloader
● IrDA transceiver
● JTAG and trace debug support, embedded ST-LINK/V2
●
4 Kbit serial Flash, 512K x16-bit SRAM and 128 Mbit NOR Flash
●
240x320 TFT color LCD connected to FSMC interface of STM32L152ZDT6
●
Joystick with 4-direction control and selector
●
Reset and Tamper or key button
●
4 color user LEDs and 3 LEDs as MCU power range indicator
●
MCU consumption measurement circuit
●
LCD glass 40 x 8 segments connected to LCD driver of STM32L152ZDT6
●
Extension connector for daughterboard or wrapping board
●
MCU voltage choice of 3.3 V or adjustable from 1.65 V to 3.6 V
●
USB FS connector
●
Touch slider
●
Light dependent resistor (LDR)
●
One MCU integrated op amp configured as Sallen-Key 2nd order low pass filter
●
One MCU integrated op amp configured as amplifier with adjustable gain
●
One ADC / DAC input signal connector
●
Potentiometer
1.2

Demonstration software

Demonstration software is preloaded in the board's Flash memory for easy demonstration of
the device peripherals in stand-alone mode. For more information and to download the
latest version available, please refer to the STM32L152D-EVAL demonstration software
available on www.st.com.
1.3

Order code

To order the STM32L152ZDT6 evaluation board, use the order code STM32L152D-EVAL.
