Schematic diagrams

This section provides the design schematics for the STM3210E-EVAL board key features, to
help you implement these features in your applications. Schematics are provided for:
Microcontroller connections, see
MCU, see Figure 17
Peripherals, see Figure 18
RS-232 and IrDA connectors, see
Audio, see Figure 20
LCD and joystick connections, see
SD Card and smartcard, see
Motor control, see Figure 23
JTAG and trace connectors, see
Power supply, see Figure 25
SRAM and Flash, see Figure 26
Color LCD module, see
Figure 16
Figure 19
Figure 21
Figure 22
Figure 24
Figure 27
