Sip Settings; Sip Anat; Sip Authentication Password; Sip Authentication Username - Cisco TelePresence SX10 Quick Set Administrator's Manual

Cisco TelePresence SX10 Quick Set

Introduction

SIP settings

SIP ANAT

ANAT (Alternative Network Address Types) enables media negotiation for multiple
addresses and address types, as specified in RFC 4091.
Requires user role: ADMIN
Default value: Off
Value space: Off/On
Off: Disable ANAT.
On: Enable ANAT.

SIP Authentication UserName

This is the username part of the credentials used to authenticate towards the SIP proxy.
Requires user role: ADMIN
Default value: ""
Value space: String (0, 128)
A valid username.

SIP Authentication Password

This is the password part of the credentials used to authenticate towards the SIP proxy.
Requires user role: ADMIN
Default value: ""
Value space: String (0, 128)
A valid password.
D15330.18 SX10 Administrator Guide CE9.12, APRIL 2020.
Configuration Peripherals Maintenance

SIP DefaultTransport

Select the transport protocol to be used over the LAN.
Requires user role: ADMIN
Default value: Auto
Value space: Auto/TCP/Tls/UDP
TCP: The device will always use TCP as the default transport method.
UDP: The device will always use UDP as the default transport method.
Tls: The device will always use TLS as the default transport method. For TLS
connections a SIP CA-list can be uploaded to the device. If no such CA-list is available
on the device then anonymous Diffie Hellman will be used.
Auto: The device will try to connect using transport protocols in the following order: TLS,
TCP, UDP.

SIP DisplayName

When configured the incoming call will report the display name instead of the SIP URI.
Requires user role: ADMIN
Default value: ""
Value space: String (0, 550)
The name to be displayed instead of the SIP URI.
www.cisco.com — Copyright © 2020 Cisco Systems, Inc. All rights reserved.
158
Administrator Guide
Device settings Device settings Appendices
