UserInterface Branding AwakeBranding Colors

If the device is set up with branding customizations, this setting affects the colors of the
logo that is shown when the device is awake. You can choose whether you want to show
the logo in full color, or reduce the opacity of the logo so that it blends in more naturally with
the background and other elements on the screen.
Requires user role: ADMIN, INTEGRATOR
Default value: Auto
Value space: Auto/Native
Auto: The opacity of the logo is reduced.
Native: The logo has full colors.

UserInterface ContactInfo Type

Choose which type of contact information to show in the user interface.
Requires user role: ADMIN
Default value: Auto
Value space: Auto/DisplayName/E164Alias/H320Number/H323Id/IPv4/IPv6/None/SipUri/
SystemName
Auto: Show the address which another device should dial to reach this video
conferencing device. The address depends on the default call protocol and device
registration.
None: Do not show any contact information.
IPv4: Show the device's IPv4 address.
IPv6: Show the device's IPv6 address.
H323Id: Show the device's H.323 ID (refer to the H323 H323Alias ID setting).
H320Number: Show the device's H.320 number as contact information (only supported
if used with Cisco TelePresence ISDN Link).
E164Alias: Show the device's H.323 E164 Alias as contact information (refer to the H323
H323Alias E164 setting).
SipUri: Show the device's SIP URI (refer to the SIP URI setting).
SystemName: Show the device's name (refer to the SystemUnit Name setting).
DisplayName: Show the device's display name (refer to the SIP DisplayName setting).
D15330.18 SX10 Administrator Guide CE9.12, APRIL 2020.
Configuration Peripherals Maintenance

UserInterface CustomMessage

A custom message can be displayed, in the lower left side of the screen, in awake mode.
Requires user role: ADMIN, INTEGRATOR
Default value: ""
Value space: String (0, 128)
Add a custom message. Add an empty string to remove a custom message.

UserInterface Diagnostics Notifications

Hide or show diagnostics notifications on the user interface.
Requires user role: ADMIN
Default value: Auto
Value space: Auto/Hidden
Auto: The diagnostics notifications will be displayed on the user interface.
Hidden: The diagnostics notifications will not be displayed on the user interface.

UserInterface KeyTones Mode

You can configure the device to make a keyboard click sound effect (key tone) when
pressing a key on the remote control, or when typing text or numbers on the Touch
controller.
Requires user role: ADMIN, USER
Default value: On
Value space: Off/On
Off: There is no key tone sound effect.
On: The key tone sound effect is turned on.
