Troubleshooting
Troubleshooting
82
5
Open the left and right extraction levers to their fully open positions.
Opening the extraction levers slides the module a short distance out of the slot,
disconnecting the module from the chassis backplane.
The IPM LED turns blue. All other LEDs turn off.
Alignment
Pin
Mounting
Knot
Extraction
Lever
6
Pull the module about half way out.
All LEDs turn off.
7
Turn both extraction levers to their fully-closed positions.
Alignment
Pin
Mounting
Knot
Extraction
Lever
8
Gently push the extraction lever lock up to make sure the extraction levers are
locked.
.
Extraction Lever
Extraction
Lever
9
Carefully slide the module completely out of the slot.
This section describes the following troubleshooting topics:
•
FortiGate-5002FB2 does not startup
Alignment
Pin
Mounting
Knot
Open
Extraction
Lever
Alignment
Pin
Mounting
Knot
Close
Extraction
Lock
FortiGate-5000 Series Hardware Guide
FortiGate-5002FB2 security system
Fully Open
Fully Closed
Lever
01-00000-0293-20060315
