FortiGate-5020 chassis

Physical description of the FortiGate-5020 chassis

Mounting the FortiGate-5020 chassis

Air flow

Connecting the FortiGate-5020 chassis to AC power

FortiGate-5000 Series Hardware Guide
01-00000-0293-20060315
The FortiGate-5020 chassis is a 4U chassis that can be installed in a standard
19-inch rack. Table 3 describes the physical characteristics of the FortiGate-5020
chassis.
Table 3: FortiGate-5020 physical description
Dimensions 5.25 x 17 x 15.5 in. (13.3 x 43.2 x 39.4 cm)
(H x W x D)
Weight 35.5 lb. (16.1 kg)
Operating environment Temperature: -13 to 158 °F (-25 to 70°C)
Relative humidity: 5 to 95% (Non-condensing)
Storage environment Temperature: -20 to 80°C
Relative humidity: 5 to 95% (Non-condensing)
Power dissipation Maximum: 800 watts
Power input 2x redundant 110 to 250 VAC
Note: Mount the FortiGate chassis before installing the FortiGate-5000 series modules.
The FortiGate-5020 chassis must be mounted in a standard 19-inch rack. The
chassis requires 4U of vertical space in the rack.
If you install the FortiGate-5020 chassis in a closed or multi-unit rack assembly,
the operating ambient temperature of the rack environment may be greater than
room ambient temperature. Make sure the operating ambient temperature does
not exceed the manufacturer's maximum rated ambient temperature.
Caution: The FortiGate-5020 chassis should not be operated as a free-standing appliance.
For rack installation, make sure that the amount of air flow required for safe
operation of the FortiGate-5020 chassis is not compromised.
The AC power connectors on the back of the FortiGate-5020 chassis provide
power to two factory installed redundant FortiGate-5020/5050 power supplies.
Each power supply distributes 800 W of 48VDC power to the entire
FortiGate-5020 chassis.
Physical description of the FortiGate-5020 chassis
