A detailed guide to the features and capabilities FortiGate-5050 chassis. This FortiGate-5050 Chassis Guide
describes FortiGate-5050 hardware features, and how to install the FortiGate-5050 chassis.
The most recent versions of this and all FortiGate-5000 series documents are available from the
page of the
Fortinet Technical Documentation
Visit
http://support.fortinet.com
FortiGate-5050 Chassis Guide
01-30000-0395-20070201
USB
1
CONSOLE
5
PWR
ACC
USB
1
CONSOLE
4
PWR
ACC
USB
1
CONSOLE
3
PWR
ACC
2
1
5000SM
5050SAP
SMC
10/100
link/Act
SERIAL
2
10/100
1
link/Act
web site (http://docs.forticare.com).
to register your FortiGate-5050 chassis. By registering you can receive product
updates, technical support, and FortiGuard services.
www.fortinet.com
C h a s s i s G u i d e
FortiGate-5050
2
3
4
5
6
7
8
STA IPM
2
3
4
5
6
7
8
STA IPM
2
3
4
5
6
7
8
STA IPM
5000SM
10/100
SERIAL
link/Act
10/100
2
link/Act
POWER
SMC
1
FortiGate-5000
Advertisement
Table of Contents
Related Manuals for Fortinet FortiGate FortiGate-5050
Summary of Contents for Fortinet FortiGate FortiGate-5050
- Page 1 FortiGate-5050 hardware features, and how to install the FortiGate-5050 chassis. The most recent versions of this and all FortiGate-5000 series documents are available from the page of the Fortinet Technical Documentation Visit http://support.fortinet.com updates, technical support, and FortiGuard services.
-
Page 2: Warnings And Cautions
Some FortiGate-5000 series components may overload your supply circuit and impact your overcurrent protection and supply wiring. Refer to nameplate ratings to address this concern. • Make sure all FortiGate-5000 series components have reliable grounding. Fortinet recommends direct connections to the branch circuit. •... -
Page 3: Table Of Contents
Using FortiSwitch-5003 modules for base backplane communication ... 24 For more information... 25 Fortinet documentation... 25 Fortinet Tools and Documentation CD ... 25 Fortinet Knowledge Center ... 25 Comments on Fortinet technical documentation ... 25 Customer service and technical support ... 25 Register your Fortinet product... - Page 4 Contents FortiGate-5050 Chassis Guide 01-30000-0395-20070201...
-
Page 5: Fortigate-5050 Chassis
FortiGate-5050 chassis FortiGate-5050 chassis You can install up to five FortiGate-5000 series modules in the five slots of the FortiGate-5050 ATCA chassis. The FortiGate-5050 is a 5U 19-inch rackmount ATCA chassis that contains two redundant DC power connections that connect to -48 VDC Data Center DC power. -
Page 6: Fortigate-5050 Front Panel
FortiGate-5050 front panel FortiGate-5050 front panel Figure 1 shows the front of a FortiGate-5050 chassis. Two FortiSwitch-5003 modules are installed in slots 1 and 2. Three FortiGate-5001SX modules are installed in slots 3, 4, and 5. The FortiGate-5050 primary and secondary Shelf Managers and the Shelf Alarm Panel (SAP) are also visible. -
Page 7: Fortigate-5050 Back Panel
FortiGate-5050 chassis FortiGate-5050 back panel Figure 2 back panel includes two redundant -48V to - 58V DC power input connectors labelled Input A and Input B. The power input connectors provide redundant DC power connections for the FortiGate-5050 chassis and distribute DC power to the fan tray and the FortiGate-5000 series modules installed in the FortiGate-5050 chassis. -
Page 8: Physical Description Of The Fortigate-5050 Chassis
Physical description of the FortiGate-5050 chassis Physical description of the FortiGate-5050 chassis FortiGate-5050 shelf alarm panel (SAP) The FortiGate-5050 chassis is a 5U chassis that can be installed in a standard 19-inch rack. Table 1 describes the physical characteristics of the FortiGate-5050 chassis. -
Page 9: Shelf Alarm Panel Telco Alarms
The external dry relay Telco alarm DB-15 Form-c interface (48VDC) provides Telco form-c male relay connections for minor, major and critical power faults. The cable required to connect to the alarm interface is not supplied by Fortinet. FortiGate-5050 shelf alarm panel (SAP) -
Page 10: Fortigate-5050 Shelf Manager
FortiGate-5050 shelf manager FortiGate-5050 shelf manager When the ACO state is activated, active alarm LEDs blink and all of the alarm relays are deactivated. The alarm reset button activates the ACO state but does not clear the alarm completely. Figure 4: The telco alarm connector (DB-15 male) Table 4: Telco alarm connector pin assignment Name AMIR+... - Page 11 FortiGate-5050 chassis The FortiGate-5050 shelf managers control chassis power up and power down, chassis power distribution, monitor chassis operating parameters, monitor and control chassis cooling, and can signal alarms if the chassis encounters problems. All FortiGate-5000 modules installed in the chassis communicate with the shelf managers.
-
Page 12: Shelf Manager Fan And Power Control
FortiGate-5050 shelf manager FortiGate-5050 chassis Shelf Manager fan and power control The FortiGate-5050 shelf managers monitor the internal temperature of the FortiGate-5050 chassis and adjust the operating speed of the FortiGate-5050 chassis cooling fan as required. If the temperature in the chassis becomes too high, the shelf managers can also power down FortiGate-5000 modules installed in the chassis to help reduce the temperature. -
Page 13: Power Connection And Configuration
About data center DC power The FortiGate-5050 chassis is designed to be installed in a data center or similar location that has available -48VDC power (also called battery power). Fortinet expects that most FortiGate-5050 customers will be installing their FortiGate... -
Page 14: Connecting A Fortigate-5050 Power Input Connector To Data Center Dc Power
Connecting the FortiGate-5050 chassis to data center DC power and data center ground Connecting a FortiGate-5050 power input connector to data center DC power The following procedure describes how to connect one FortiGate-5050 power input connector to data center DC power. For normal operation, only power input connector A must be connected. -
Page 15: Connecting The Fortigate-5050 Chassis To Data Center Ground
Power connection and configuration Connecting the FortiGate-5050 chassis to AC power using the FortiGate-5053 power converter tray Connecting the FortiGate-5050 chassis to data center ground The FortiGate-5050 chassis has a ground connections on the lower left side of the FortiGate-5050 back panel (see connected to data center ground. -
Page 16: Fortigate-5053 Power Converter Tray Front And Back Panel
Connecting the FortiGate-5050 chassis to AC power using the FortiGate-5053 power converter tray Power connection and configuration FortiGate-5053 power converter tray front and back panel The front panel of the FortiGate-5053 power converter tray (shown in provides access to the FortiGate-5020/5050 power supplies. Figure 8: Front panel of the FortiGate-5053 power converter tray with one power supply removed Slot 3... -
Page 17: Selecting The Power Supplies And Power Converter Trays That You Need For Your Fortigate-5050 Configuration
FortiGate-5050 chassis. This section provides guidelines only. Actual requirements may vary depending on your installation requirements. Contact Fortinet Technical Support if you need more information. The FortiGate-5053 power converter tray contains space for up to three FortiGate-5020/5050 power supplies. - Page 18 Connecting the FortiGate-5050 chassis to AC power using the FortiGate-5053 power converter tray Power connection and configuration Figure 10: Non-redundant power for all FortiGate-5050 chassis slots 1 FortiGate-5053 power convertor tray Slot 3 Slot 2 Slot 1 2 FortiGate-5020/5050 power supplies 2 x 800W = 1600W 1 FortiGate-5050 Redundant FortiGate-5050 power supplies...
- Page 19 Power connection and configuration Connecting the FortiGate-5050 chassis to AC power using the FortiGate-5053 power converter tray Figure 12: Redundant FortiGate-5053 power converter trays Slot 3 Slot 3 Figure 13: Redundant FortiGate-5053 power converter trays and 2 + 1 redundant Slot 3 Slot 3 2 x 800W = 1600W...
-
Page 20: Connecting A Fortigate-5050 Chassis To The Fortigate-5053 Power Converter Tray
Connecting the FortiGate-5050 chassis to AC power using the FortiGate-5053 power converter tray Power connection and configuration Connecting a FortiGate-5050 chassis to the FortiGate-5053 power converter tray To use a FortiGate-5053 power converter tray with the FortiGate-5050 chassis you need to make DC power connections between the FortiGate-5050 chassis and the FortiGate-5053 power converter tray. - Page 21 Power connection and configuration Connecting the FortiGate-5050 chassis to AC power using the FortiGate-5053 power converter tray Figure 14: Connecting a FortiGate-5050 power input connector to a FortiGate-5053 FortiGate-5053 Power wire fixture Make sure the power wires are secured to the chassis using the power wire fixture and tie wraps if required.
-
Page 22: Turning On Fortigate-5050 Chassis Power
Turning on FortiGate-5050 chassis power Power connection and configuration Figure 15: Wiring the FortiGate-5053 power converter tray To connect the FortiGate-5050 chassis to data center ground The FortiGate-5053 power converter tray does not have a ground connector. So, even if you are using a FortiGate-5053 power converter tray to supply DC power to your FortiGate-5050, you must use the procedure “To connect the FortiGate-5050 chassis to data center ground”... -
Page 23: Fortigate-5050 Hardware Procedures
FortiGate-5050 hardware procedures FortiGate-5050 hardware procedures This chapter assumes the chassis has been mounted and connected to a power source as detailed in This chapter discusses: • Mounting the FortiGate-5050 chassis • Inserting 5000 series modules into a FortiGate-5050 chassis •... -
Page 24: Using Fortiswitch-5003 Modules For Base Backplane Communication
Using FortiSwitch-5003 modules for base backplane communication Using FortiSwitch-5003 modules for base backplane communication Caution: FortiGate-5000 series and FortiSwitch-5000 series modules must be protected from static discharge and physical shock. Only handle or work with FortiGate-5000 series and FortiSwitch-5000 series modules at a static-free workstation. Always wear a grounded electrostatic discharge (ESD) preventive wrist or ankle strap when handling FortiGate-5000 series or FortiSwitch-5000 series modules. -
Page 25: For More Information
Fortinet Tools and Documentation CD All Fortinet documentation is available from the Fortinet Tools and Documentation CD shipped with your Fortinet product. The documents on this CD are current for your product at shipping time. For the latest versions of all Fortinet documentation see the Fortinet Technical Documentation web site at http://docs.forticare.com. - Page 26 © Copyright 2007 Fortinet, Inc. All rights reserved. No part of this publication including text, examples, diagrams or illustrations may be reproduced, transmitted, or translated in any form or by any means, electronic, mechanical, manual, optical or otherwise, for any purpose, without prior written permission of Fortinet, Inc.
