Removing a FortiGate-5002FB2 module from a chassis

Removing a FortiGate-5002FB2 module from a chassis
80
8 Fully tighten the left and right mounting knots to lock the FortiGate-5002FB2
module into position in the chassis slot.
.
Mounting
Knot
Tighten
If the chassis is powered on the PWR LED turns green and the STATUS LED
turns RED. After a few minutes, if the module is operating correctly the front panel
LEDs are lit as described in
Table 14: FortiGate-5002FB2 normal operating LEDs
LED State
STATUS Green
PWR Green
IPM Off
9 Gently push the extraction lever lock up to make sure the extraction levers are
locked.
Extraction Lever
Extraction
Lever
The following procedure describes how to correctly use the FortiGate-5002FB2
mounting components shown in
module from a FortiGate-5000 series chassis slot.
To remove a FortiGate-5002FB2 module from a FortiGate-5000 series
chassis
FortiGate-5002FB2 modules are hot swappable. The procedure for removing the
FortiGate-5002FB2 module from a FortiGate-5000 series chassis slot is the same
whether or not the FortiGate-5000 series chassis is powered on or not.
Table 14.
Lock
Figure 38 to remove a FortiGate-5002FB2
FortiGate-5000 Series Hardware Guide
FortiGate-5002FB2 security system
01-00000-0293-20060315
