Troubleshooting

Troubleshooting

FortiGate-5001FA2 does not startup

70
5 Open the left and right extraction levers to their fully open positions.
Opening the extraction levers slides the module a short distance out of the slot,
disconnecting the module from the chassis backplane.
The IPM LED turns blue. All other LEDs turn off.
Alignment Pin
Extraction
Lever
Open
6 Pull the module about half way out.
All LEDs turn off.
7 Turn both extraction levers to their fully-closed positions.
When the extraction levers are fully-closed they lock into place.
Alignment Pin
Close
8 Carefully slide the module completely out of the slot.
This section describes the following troubleshooting topics:
• FortiGate-5001FA2 does not startup
• FortiGate-5001FA2 cannot display chassis information
Positioning of FortiGate-5001FA2 extraction levers, the presence or absence of a
functioning shelf manager, incorrect jumper settings and firmware problems may
all prevent a FortiGate-5001FA2 module for starting up correctly. This section
describes how to find and fix each of these problems.
All chassis: left extraction lever not contacting power switch
The left extraction lever activates the FortiGate-5001FA2 module power switch.
FortiGate-5001FA2 security system
Extraction
Lever
Fully Open
Alignment Pin
Extraction
Lever
