USB status

xStatus USB Device [n] State

Shows the USB device state.
Requires user role: ADMIN, INTEGRATOR, USER
Value space of the result returned:
Empty/Unsupported/Supported
Example:
xStatus USB Device 1 State
*s USB Device 1 State: Supported
** end

xStatus USB Device [n] Type

Shows the USB device type.
Requires user role: ADMIN, INTEGRATOR, USER
Value space of the result returned:
Ethernet/Unknown/None
Example:
xStatus USB Device 1 Type
*s USB Device 1 Type: Ethernet
** end
SX20 Codec API Reference Guide CE9.1, JUNE 2017.
D15316.07
About the API xConfiguration xCommand

UserInterface status

xStatus UserInterface ContactInfo ContactMethod [n] Number

Returns the system's active contact information. This address is used to reach this endpoint.
Requires user role: ADMIN, USER
Value space of the result returned:
String
Example:
xStatus UserInterface ContactInfo ContactMethod Number
*s UserInterface ContactInfo ContactMethod 1 Number: "12345678"
** end

xStatus UserInterface ContactInfo Name

Returns the system's active contact name. The result depends on which protocol, if any, the
system is registered on. The automatically set contact name may have been overridden with the
command xConfiguration UserInterface ContactInfo Type. This results in a diagnostics warning
about contact mismatch.
Requires user role: ADMIN, USER
Value space of the result returned:
String
Example:
xStatus UserInterface ContactInfo Name
*s UserInterface ContactInfo Name: "MySystem"
** end

xStatus UserInterface Extensions Widget [n] Value

Returns the value for a widget. Widgets are used in custom panels, for example in-room
controls, that are added to the user interface. The value space depends on the widget type.
The value is an empty string until a value is set with the UserInterface Extensions Widget
SetValue command.
Requires user role: ADMIN, INTEGRATOR, USER, ROOMCONTROL
Value space of the result returned:
String
